Bra RIAA-steg i smidigt format.

Nytt RIAA-steg med kompakt design och med sedvanligt hög prestanda som gjort MOON erkända över hela världen!

Analog reproduction with world-class performance. Yet easy to use and affordable. Your records will never have sounded so good.

Design features:

• End-user adjustable impedance loading (47kΩ, 475Ω, 100Ω, 10Ω)
• End-user adjustable capacitance loading (0pF, 100pF, 330pF, 430pF)
• End-user adjustable gain settings for moving magnet and moving coil cartridges (40dB, 50dB, 54dB, 60dB, 66dB)
• End user selectable curve (IEC/RIAA)
• Four layer PCB tracings using pure copper for low impedance characteristics
• Inductive DC Filtering for a significantly lower noise floor
• Compact, rigid all-aluminum chassis with gold-plated RCA connectors
• Designed to be powered up at all times for optimal performance

Specifications:

• Circuit Layout: Mirror-image symmetrical circuit
• Single-ended inputs: 1 pair (RCA)
• Input Impedance - Adjustable: 10Ω / 100Ω / 475Ω / 47kΩ
• Input Capacitance - Adjustable: 0 / 100pF / 330pF / 430pF
• Gain Level - Adjustable: 40dB / 50dB / 54dB / 60dB / 66dB
• Curve: IEC / RIAA
• Signal-to-noise Ratio (full scale @40 dB gain) 104 dB
• Signal-to-noise Ratio (full scale @60 dB gain) 87 dB
• Frequency Response: 20Hz - 20kHz (± 0.5dB)
• Intermodulation Distortion: 0.002%
• THD (20Hz - 20kHz) 0.002%
• Power Consumption @ idle: 2 W
• AC Power Requirements: 100-240V 50Hz / 60 Hz
• Dimensions (BxHxD) 127x42x165mm
• Shipping Weight: 1.5 kg
